Rain Bird® Y74007 76A-5004PCR
  1. pin-int

Rain Bird® Y74007 76A-5004PCR

Rain Bird® 5000 Series Y74007 Rotor, 15 to 50 ft Operating, 3/4 in, NPT

  • Manufacturer: Rain Bird
  • Brand Name: Rain Bird®
  • Part#: 76A-5004PCR
  • MPN: Y74007
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading Available at Vero Beach
  • loading Available at All Branches

Rain Bird® Rotor, 5000 Series, 15 to 50 ft Operating, Part-Circle, Uniform Spray Pattern, 20 to 65 psi, 0.76 to 9.63 gpm Flow Rate, Precipitation Rate: 0.20 to 1.01 in/hr, 4 in Pop-Up Height, 3/4 in Connection, NPT Connection, 7-3/8 in Overall Height

SPECIAL_ORDER_ITEM      :      N
Special Order Item      :      N
  • Faster maintenance with a new self-cleaning arc adjustment screw
  • Heavy-duty cover assembly for extra durability
  • Rain Curtain nozzles
  • Slip clutch mechanism for quick adjustment on installation
  • Heavy-duty retract spring assures positive pop-down
  • Radius adjustment screw allows up to 25% radius reduction without changing nozzles
  • Pressure activated multi-function wiper seal protects internals from debris and assures positive pop-up and retraction
  • Reinforced flow path for additional side load strength
  • Additional O-rings and seals for extra protection in gritty water
  • Pressure regulating stem (PRS) regulates pressure at the head, assuring optimum performance
  • pdfCatalog https://assets.unilogcorp.com/267/ITEM/DOC/Rain_Bird_Y34000_Catalog.pdf
