Flomatic® C152001ET 56A-C152001ET
Flomatic® C152ET Series C152001ET Direct Acting Pump Control Valve, 1 in Nominal, FNPT x MNPT, 400 psi, 180 deg F
- Manufacturer: Flomatic Corporation
- Brand Name: Flomatic®
- Part#: 56A-C152001ET
- MPN: C152001ET
- Min. Order Qty: 1
- Qty. Interval: 1
-
Available at Vero Beach
-
Available at All Branches
-
Price:
Direct acting constant pressure pump control valve - dual purpose threads, reduces rapid pump cycling and maintains a pre-set operating pressure for pump systems. 1 in FNPT ID x 1-1/4 in male OD on inlet and outlet connections. Features an unleaded body and composite bell housing, Nylon reinforced Buna-N diaphragm.
Flomatic® Direct Acting Pump Control Valve, C152ET Series, 1 in Nominal, FNPT x MNPT Connection, 400 psi, Bronze Body, 180 deg F, 4 in L x 7-5/8 in H
| SPECIAL_ORDER_ITEM | : | N |
| Special Order Item | : | N |
- Lead-free
- Maintains a constant pressure
- Stops pump from cycling
- Hydraulically operated
- Extends pump motor life
- Eliminates effects of water hammer
- Easy-to-install
- Field adjustable
- Downsize the tank size
- Steel adjusting screw, jam nut, spring button, spring, diaphragm plate, tooth lock washer, nitrile/nylon diaphragm, C36000 brass friction ring, Delrin cartridge, 18-8 stainless steel screw, 303 stainless steel slotted disc
