Spears® S1520-80 SO-53-080
  1. pin-int

Spears® S1520-80 SO-53-080

Spears® S1520-80 Utility Swing Check, 8 in, Socket, PVC

  • Manufacturer: Spears Manufacturing
  • Brand Name: Spears®
  • Part#: SO-53-080
  • MPN: S1520-80
  • UPC: 054211479001
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading Available at Vero Beach
  • loading Available at All Branches

Spears® utility swing check valves offer a compact, high performance check valve for landscape and irrigation, pool and spa, aquaculture, OEM and many general purpose applications. These maintenance-free sealed units feature long life EPDM elastomer seats with weighted disc for full flow with minimal restriction and positive shut-off.

Spears® Utility Swing Check, 8 in Nominal, Socket Connection, 150 psi, 73 deg F, Water Media, 11-3/16 in Inlet to Outlet Length, 9-7/16 in Opening, PVC Body, EPDM Seat, EPDM Softgoods, White, 19-1/4 in L x 11-15/16 in H

Body Material      :      PVC
Color      :      White
Connection Type      :      Socket
Dimensions      :      19-1/4 in L x 11-15/16 in H
Inlet to Outlet Length      :      11-3/16 in
Media      :      Water
Nominal Size      :      8 in
Opening Size      :      9-7/16 in
Pressure Rating      :      150 psi
SPECIAL_ORDER_ITEM      :      Y
Seat Material      :      EPDM
Softgoods Material      :      EPDM
Special Order Item      :      Y
Temperature Rating      :      73 deg F
  • Chemical and corrosion-resistant PVC white construction
  • Maintenance-free sealed unit in a compact space saving design
  • Engineered for maximum flow, quick response and positive shut-off
  • Long life, high-grade EPDM seat with weighted disc
  • Suitable for either horizontal or vertical up flow installations and vacuum service
  • NSF certified for potable water use
  • Silicone-free assembly
