Flomatic® C152004E 56A-C152004E
Flomatic® C152E Series C152004E Direct Acting Pump Control Valve, 2 in Nominal, FNPT, 70 gpm, Bronze
- Manufacturer: Flomatic Corporation
- Brand Name: Flomatic®
- Part#: 56A-C152004E
- MPN: C152004E
- Min. Order Qty: 1
- Qty. Interval: 1
-
Available at Vero Beach
-
Available at All Branches
-
Price:
Direct acting constant pressure pump control valve - reduces rapid pump cycling and maintains a pre-set operating pressure for pump systems. Threaded female x female connection. Features an unleaded body and composite bell housing, nylon reinforced Buna-N diaphragm. Supplied with two FNPT tail piece and union nuts.
Flomatic® Direct Acting Pump Control Valve, C152E Series, 2 in Nominal, FNPT Connection, 70 gpm Flow Rate, Water Media, 8-1/8 in Inlet to Outlet Length, 400 psi, 180 deg F, Material Standard: C89833, Bronze, 304 Stainless Steel Stem, 9-15/16 in L x 8-1/8 in W, Additional Information: 15 to 75 psi Spring
| SPECIAL_ORDER_ITEM | : | N |
| Special Order Item | : | N |
- Maintains a constant pressure
- Stops pump from short cycling
- Hydraulically operated (no electricity required)
- Extends pump motor life
- Eliminates effects of water hammer
- More compact system
- Easy-to-install
- Field adjustable
- Downsize the tank
- Provides more efficient use of appliances
