Senninger® PR30HF5F4FV SO-56A-SENPR30HF
  1. pin-int

Senninger® PR30HF5F4FV SO-56A-SENPR30HF

Senninger® PR-HF Series PR30HF5F4FV Irrigation Water Pressure Regulator, 1-1/4 in Inlet Connection, 10 to 32 gpm

  • Manufacturer: Senninger Irrigation
  • Brand Name: Senninger®
  • Part#: SO-56A-SENPR30HF
  • MPN: PR30HF5F4FV
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • loading Available at Vero Beach
  • loading Available at All Branches

The PR-HF (pressure regulator high flow) is ideal for installations requiring higher flows of 10 to 32 gpm (2271 to 7268 Lph), including solid set sprinkler and low volume manifolds.

Senninger® Irrigation Water Pressure Regulator, 1-1/4 in Inlet Connection, 1 in Outlet Connection, 30 psi Operating Pressure, 10 to 32 gpm Flow Rate, Thermoplastic Body, 5.6 in Length, 2.9 in Width, Additional Information: FNPT Connection

Additional Information      :      FNPT Connection
Body Material      :      Thermoplastic
Flow Rate      :      10 to 32 gpm
Inlet Connection Size      :      1-1/4 in
Length      :      5.6 in
Operating Pressure      :      30 psi
Outlet Connection Size      :      1 in
SPECIAL_ORDER_ITEM      :      Y
Series      :      PR-HF Series
Special Order Item      :      Y
Width      :      2.9 in
  • Senninger® irrigation water pressure regulators maintain a constant preset outlet pressure with varying inlet pressures, which alleviates pressure differences that can cause an applicator's area of coverage to change
  • 100% pressure tested, to ensure quality and performance
  • Very low hysteresis and friction losses
  • Can be installed above or below ground
  • pdfCatalog https://assets.unilogcorp.com/267/ITEM/DOC/Senninger_PMR06MF3F3FV_Catalog.pdf
  • pdfSpecification Sheet https://assets.unilogcorp.com/267/ITEM/DOC/Senninger_PR30HF5F4FV_Specification_Sheet.pdf
