Liberty Pumps® LE52A-2 60A-L-LE52A-2
Liberty Pumps® LE52A-2 Manual Sewage Pump, 208 to 230 V, 6.8 A, 60 Hz, 1/2 hp, 158 gpm, 10.8 psi
- Manufacturer: Liberty Pumps
- Brand Name: Liberty Pumps®
- Part#: 60A-L-LE52A-2
- MPN: LE52A-2
- Min. Order Qty: 1
- Qty. Interval: 1
-
Available at Vero Beach
Available at All Branches
-
Price:
Liberty Pumps LE50-Series cast iron sewage pump is a commercial-grade workhorse for residential and light commercial applications. Its efficient 1/2 hp motor with permanently lubricated bearings, stainless steel fasteners and Quick-connect power cord design make this a favorite choice among professionals. Other features include 2" solids handling ability and a shut-off head of 25 feet. The LE52A-2 variant operates at 208-230V and includes a 25' power cord.
Liberty Pumps® Manual Sewage Pump, LE50 Series, Model: LE52A-2, 208 to 230 V, 6.8 A, 1/2 hp, 60 Hz, 1/2 hp, 1725 rpm, 158 gpm Flow Rate, 1 pHase, 2 in Suction, 2 in Discharge, 25 ft Cord Length, 2 in Solids Capacity, Maximum Feet of Head: 25 ft, Insulation Class: Class B, Submersible Mounting, 10.8 psi, 104 deg F Continuous, 140 deg F Intermittent, Engineered Thermoplastic Elastomer Impeller, 11-1/2 in L x 7-1/2 in W x 12 in H, Iron/Stainless Steel/Thermoplastic Elastomer, Powder-Coated
| Amperage Rating | : | 6.8 A |
| Capacity | : | 2 in Solids |
| Cord Length | : | 25 ft |
| Dimensions | : | 11-1/2 in L x 7-1/2 in W x 12 in H |
| Discharge Size | : | 2 in |
| Finish | : | Powder-Coated |
| Flow Rate | : | 158 gpm |
| Frequency Rating | : | 60 Hz |
| HP Rating | : | 1/2 hp |
| Impeller Material | : | Engineered Thermoplastic Elastomer |
| Insulation Class | : | Class B |
| Material | : | Iron/Stainless Steel/Thermoplastic Elastomer |
| Maximum Feet of Head | : | 25 ft |
| Model | : | LE52A-2 |
| Mounting Type | : | Submersible |
| Phase | : | 1 ph |
| Power Rating | : | 1/2 hp |
| Pressure Rating | : | 10.8 psi |
| Series | : | LE50 Series |
| Speed Rating | : | 1725 rpm |
| Suction Size | : | 2 in |
| Temperature Rating | : | 104 deg F Continuous, 140 deg F Intermittent |
| Voltage Rating | : | 208 to 230 V |
- Rugged 2-vane, semi-open cast iron impeller|iron housings with all stainless steel fasteners|motors with thermal overload protection|25' cords|in 2" or 3" discharge|adjustable wide-angle float switch|hermetically sealed motors|lubricated upper and lower ball bearings|steel rotor shaft|shaft seal|warranty|hp / 2" Solids handling
Instruction/Installation Manual
Video Link 1
